Elkomix-35 Quick Master

Elkomix-35 Quick Master

ELKOMIX-35 QUICK MASTER which is the lowest capacity member of ELKON Quick Master Compact Concrete Batching Plant Series. It can be quickly and economically transported to anywhere in the world by only 1 unit 40’ OT container (or by a TIR) thanks to its folding and modular designed structure.

ELKON Compact Concrete Batching Plants, which reflect ELKON's manufacturing culture based on high technology and experience since 1975, provides the following advantages to its users:

Mixer Types
Production Types

30

Product Size Image

/h

  • Quick and easy installation (only 1 day)
  • Cost effective sea and land transportation (by 1 unit 40’OT Container or 1 unit TIR)
  • Possibility of installation on a confined space (12x17 meters)
  • Quick and easy relocation
  • Flexibility in the configuration
  • Minimum foundation cost (only flat concrete surface is adequate for installation)
  • Easy maintenance and low operating costs
  • High production performance with optimized automation system

FEATURES

Capacity

30 m³/h

Mixer Capacity

750 / 500 l.

Mixer Type

Pan / Planetary

Aggregate Storage Bin Capacity

4x7,5 / 3x10 m³

Aggregate Loading Type

Skip Bucket

DETAILS

ELKON engineers aspired to combine the advantages of mobile concrete batching plants along with the easy transportation advantage to overseas by standard containers when designing Quick Master Compact Concrete Batching Plant series. As a consequence, it was achieved to reduce the shipping costs 3-4 times depending on the destination.

Elkomix-35 Quick Master compact concrete batching plant, which is pre-installed and pre-wired in ELKON factories before the shipment, can be ready for concrete production by commissioning in a day.

Elkomix-35 Quick Master Compact Concrete Batching Plant along with 1 unit cement silo and an aggregate loading ramp can be installed on as small space as 12x17 meters, which makes its users more flexible and comfortable.
